30CS

Where the action is

Built for demanding recoveries, the 30CS will quickly become a very handy unit in your fleet. It can tow pickup trucks to loaded tractor-trailers, and then some. Add a Tag Axle, and turn your 30CS into an unbeatable towing machine.

Slide the mast, extend the boom and perform recoveries you thought impossible, with an ease you have never experienced.

What more could you ask for? Reach, of course! Compare our 30CS to the same category competing model and be wowed by the lightweight, easy-to-use 2-stage boom, allowing you to reach the load no matter what.

  • 30-Ton Rated lifting capacity
  • 78'' Sliding recovery boom
  • Working hydraulic pressure 3000 PSI
  • Composite body 101.5'' wide (including fenders)
  • 2-stage V-shaped recovery boom
  • Boom structural rating fully retracted: 60,000 lbs
  • Boom structural rating fully extended: 25,000 lbs
  • Reach past tailgate: 169"
  • Maximum Boom working height : 300"
  • Range of elevation : 0° - 63°
  • 360° sheave head
  • Dual 30,000 lbs planetary winches
  • 5/8” x 200’ wire ropes
  • Air tensioners
  • Air free spools
  • Tandem axle body
  • Stylish monocoque corrosion resistant composite storage cabinets
  • Air actuated sliding locks
  • Lock & safety valve on elevation and extension cylinders
  • Dual hydraulic controls with lighting
  • Electric switches with rear controls
  • 6 button wireless remote control
  • 6 button CAN BUS keypad in the cab for lighting control
  • Removable spades
  • Rear mounted recovery anchors
  • Mud flaps
  • LED Lights
  • Modular Fork and accessory holders
  • Emergency stop switches
  • Epoxy primer
  • Anodized aluminium roll-up doors
  • Proportional joysticks at main control station
  • Fully proportional remote control with 2 batteries and charger
  • 10/14-button wireless remote control
  • Full width rear stabilizer with multi-function spades
  • 5" color touch screen
  • Scale system
  • "L" shaped mounting plates 3/8"
  • 3-stage HD/SHD Underlift
  • 4-stage SHD Underlift
  • Heavy duty tire lift
  • Composite winch covers
  • Large tunnel tool box (28" to 72")
  • Composite battery box on top of tunnel
  • Composite light pylon
  • Work lights under the boom (up to 2)
  • 2 work lights under the bumper
  • Stainless docking lights
  • Lifting beam / spreader bars
  • Configurable toolbox organizers
  • Stainless dress-up kit
  • Installation
  • Custom paint
  • Front Axle : Minimum 14,600 lbs capacity
  • Rear Axle : Minimum 40,000 lbs capacity
  • Minimum frame RBM: 3,250,000 in.lbs per rail
  • Minimum CLA 146" for tandem axle body (from cab to center of rearmost axle)
